Engineered for versatility, the ZHJ-500SF cartoning machine ensures process-safe, efficient packaging with fast changeovers and an interchangeable closing station, adapting seamlessly to diverse product lines.
GET A QUOTE
DOWNLOAD
Flexible and efficient
An contunious motion cartoner of the latest machine generation with excepxionally straightforward operating functions. Maximum reliability for the packaging of blisters, bottles, vials, or pillow packs, for example.
| cartoner part | Specifcation of carboard case (L×W×H) | (75-210)×(33-85)×(15-75)mm |
| Leaflet of medicine (L×W) | (60-200)×(90-300)mm | |
| Leaflet quality requirement | 60-75 g/m² | |
| Cartoner speed | 400 carton/min | |
| Pressure | 0.6-0.8 mpa | |
| Power | 380V 50Hz | |
| Packaging demensions (L×W×H) | 13400×2600×2000mm | |
| Weight | 12000 kg | |
| Total power of machine | 38KW | |
| Total air-consumption (max) | 500 L/min | |
 |
 |
 |
 |
 |
 |
