Designed for ease and efficiency, the ZHJ-400SZ cartoning machine enables fast format changes and features excellent accessibility for cleaning. Its smart control system automatically diagnoses stoppages, ensuring a smooth and user-friendly operation.
GET A QUOTE
DOWNLOAD
It is suitable for packing pharmaceutical aluminum plastic and other related similar content compact with automatic fish folding,forming opening and loading, batch number printing as well as sealing tec processes.lt adopts PLC control, photoelectrictry supervision to coordinate with every parts.Once something unexpected happens when its operating. It can stop and display the reasons automatically.it is convenient to solve the troubles in time. this machine can be used separately, and also can used with other blister packing machines.
| cartoner part | Specifcation of carboard case (L×W×H) | (65-210)×(33-85)×(16-70)mm |
| Leaflet of medicine (L×W) | (100-190)×(100-260)mm | |
| Leaflet quality requirement | 60-75 g/m² | |
| Cartoner speed | 200-400 carton/min (According to the demension and shape of plate) | |
| Pump | Air-consumption | >0.2m³ |
| Pressure | 0.5-1.0Mpa | |
| Power | 380V 50Hz | |
| Packaging demensions (L×W×H) | 13000×1800×1800mm | |
| Weight | 10000 kg | |
| Total power of machine | 32KW | |
| Total air-consumption (max) | 500 L/min | |
 |
 |
 |
 |
 |
 |
