The ZHJ-400 High-Speed Automatic Cartoning Machine delivers uncompromising efficiency and process-safe reliability for diverse packaging needs, all through user-friendly operation and a quiet, protected design.
GET A QUOTE
DOWNLOAD
In view of the multitude of packaging forms and inserts in the packaging process, those unwilling to compromise in terms of productivity require customized equipment; cartoners plus suitably coordinated feeding systems and accessories to ensure smooth processes.
| cartoner part | Specifcation of carboard case (L×W×H) | (65-210)×(35-85)×(16-70)mm |
| Leaflet of medicine (L×W) | (100-260)×(100-190)mm | |
| Leaflet quality requirement | 60-75 g/m² | |
| Cartoner speed | 200-400 carton/min (According to the demension and shape of plate) | |
| Main motor power | 3.7KW | |
| Power | 380V 50Hz | |
| Pressure | 0.6-0.8 mpa | |
| Packaging demensions (L×W×H) | 3900×1700×1750mm | |
| Weight | 2500 kg | |
| Total power of machine | 6KW | |
| Total air-consumption (max) | 100 L/min | |
 |
 |
 |
 |
 |
 |
